Szczegóły Produktu
Miejsce pochodzenia: Chiny
Nazwa handlowa: Tankii
Orzecznictwo: ISO9001 Rohs
Numer modelu: Karma
Warunki płatności i wysyłki
Minimalne zamówienie: 10 kg
Cena: negocjowalne
Szczegóły pakowania: drewniana skrzynka
Czas dostawy: 15-25 dni
Zasady płatności: Akredytywa, T/T, Western Union
Możliwość Supply: 2000 ton rocznie
Tworzywo: |
Ni80Cr20 |
Czystość: |
80%Ni |
Typ: |
Stop niklu |
Kolor: |
Srebrno-biały |
Powierzchnia: |
Jasny |
Próbka: |
Zaakceptowano Samll |
Gęstość: |
8.1 (g/cm3) |
Tworzywo: |
Ni80Cr20 |
Czystość: |
80%Ni |
Typ: |
Stop niklu |
Kolor: |
Srebrno-biały |
Powierzchnia: |
Jasny |
Próbka: |
Zaakceptowano Samll |
Gęstość: |
8.1 (g/cm3) |
Evanohm /Karma/ Nickel /tin / Cr20Ni80 / Ni80Cr20/NiCr80/20 foil 0.008mm
nickel 200 strip
1.Grade:Ni200,Ni201,N4,N6
2.Purity: 99.6%
3.Density: 8.9g/cm3
4.Certification: ISO9001,ISO14001,CE
| Item Name | GETWICK Nickel Strip |
Material |
Pure Nickel and Alloy Nickel |
Grade |
Ni200,Ni201,N4,N6 |
Purity |
99.6% |
| Specification | Thick 0.01mm min. |
Applications |
1)70% Ni was used for produce stainless steel and heat resistance steel 2)15% of the Ni in the world was used as electroplating. 3)Used as catalyst in oil industry |
nickel 200 strip Chemical requirements
| Name | Chemical Comsitions | ||||||
| Pure Nickel | Ni | Mn | C | Mg | Si | Fe | Others |
| 99.9 | 0.01 | 0.01 | 0.01 | 0.02 | 0.04 | <0.01 | |
Specification
| Item Name | nickel 201 strip | ||
| Grade | Ni4,Ni6 | ||
| Specification(mm) | Thickness | Width | Length |
| 0.05-0.15 | 20-250 | More than 5000 | |
| 0.15-0.55 | More than 3000 | ||
| 0.55-1.2 | More than 2000 | ||
| Supply Form | Titanium strips coiling | ||
| Applications | 1)Manufacture and handling of sodium hydroxide, particularly at temperature above 300°C. 2) Production of viscose rayon. Manufacture of soap. 3) Analine hydrochloride production and in the chlorination of aliphatic hydrocarbons such as benzene, methane and ethane. 4) Manufacture of vinyl chloride monomer. 5) Storage and distribution systems for phenol - immunity from any for of attack ensures absolute product purity. |
||
Nickel Chromium Alloy Strip (Ni80Cr20)
Grade: Ni80Cr20
Resistivity: 1.09 ohm mm2/m
Chemical Composition: Nickel 80%, Chrome 20%
Condition: Bright, Annealed, Soft
Dimension: Width 1~300mm, Thickness 0.01~7mm
Producer: Shanghai Tankii Alloy Material Co., Ltd.
Mechanical Properties
| Max Continuous Service: Fast Life(1200ºC) Resisivity( 20ºC)/Ω·m: Density: Thermal Conductivity: Coefficient of Thermal Expansion: Melting Point: Elongation: Micrographic Structure: Magnetic Property: |
1200ºC Min 80 hours 1.09 +/-0.05 (Dia: <0.5mm) 1.13+/-0.05 (Dia: 0.50-3.00 mm) 1.14+/-0.05 (Dia: >3.0mm) 8.4 g/cm3 60.3 KJ/m·h·ºC 18.0 α×10-6/ºC 1400 ºC Min 20% Austenite nonmagnetic |
