Szczegóły Produktu
Miejsce pochodzenia: Szanghaj, Chiny
Nazwa handlowa: TANKII
Orzecznictwo: ISO9001
Numer modelu: FeNi29Co18
Warunki płatności i wysyłki
Minimalne zamówienie: 5 kg
Cena: negocjowalne
Szczegóły pakowania: karton + drewniana skrzynka
Czas dostawy: 7-20 dni
Zasady płatności: Akredytywa, T/T, Western Union
Możliwość Supply: 100 ton miesięcznie
OD: |
0,3 mm Min. |
WT: |
0,01 mm min. |
Tworzywo: |
Zestaw niklu żelaza |
Kształt: |
taśma, pręt, drut, blacha, rura |
Aplikacja: |
Przemysł, przemysł elektryczny i elektroniczny, grawerowanie CNC, przemysł instrumentów precyzyjnych |
Gęstość: |
8,20 g/cm3 |
Powierzchnia: |
Jasna powierzchnia |
OD: |
0,3 mm Min. |
WT: |
0,01 mm min. |
Tworzywo: |
Zestaw niklu żelaza |
Kształt: |
taśma, pręt, drut, blacha, rura |
Aplikacja: |
Przemysł, przemysł elektryczny i elektroniczny, grawerowanie CNC, przemysł instrumentów precyzyjnych |
Gęstość: |
8,20 g/cm3 |
Powierzchnia: |
Jasna powierzchnia |
TK411-29 (Kovar Expansion alloy)
(Common Name: Kovar, Nilo K, KV-1, Dilver Po, Vacon 12) TK411-29 also known as Kovar alloy. it was invented to meet the need for a reliable glass-to-metal seal, which is required in electronic devices such as light bulbs, vacuum tubes, cathode ray tubes, and in vacuum systems in chemistry and other scientific research. Most metals cannot seal to glass because their coefficient of thermal expansion is not the same as glass, so as the joint cools after fabrication the stresses due to the differential expansion rates of the glass and metal cause the joint to crack.
K411-29 was invented to meet the need for a reliable glass-to-metal seal, which is required in electronic devices such as light bulbs, vacuum tubes, cathode ray tubes, and in vacuum systems in chemistry and other scientific research. Most metals cannot seal to glass because their coefficient of thermal expansion is not the same as glass, so as the joint cools after fabrication the stresses due to the differential expansion rates of the glass and metal cause the joint to crack.
K411-29 not only has thermal expansion similar to glass, but its nonlinear thermal expansion curve can often be made to match a glass, thus allowing the joint to tolerate a wide temperature range. Chemically, it bonds to glass via the intermediate oxide layer of nickel oxide and cobalt oxide; the proportion of iron oxide is low due to its reduction with cobalt. The bond strength is highly dependent on the oxide layer thickness and character. The presence of cobalt makes the oxide layer easier to melt and dissolve in the molten glass. A grey, grey-blue or grey-brown color indicates a good seal. A metallic color indicates lack of oxide, while black color indicates overly oxidized metal, in both cases leading to a weak joint.
Mainly used in electric vacuum components and emission control, shock tube, igniting tube, glass magnetron, transistors, seal plug, relay, integrated circuits lead, chassis, brackets and other housing sealing.
ormal composition%
| Ni | 28.5~29.5 | Fe | Bal. | Co | 16.8~17.8 | Si | ≤0.3 |
| Mo | ≤0.2 | Cu | ≤0.2 | Cr | ≤0.2 | Mn | ≤0.5 |
| C | ≤0.03 | P | ≤0.02 | S | ≤0.02 |
Tensile Strength, MPa
| Code of condition | Condition | Wire | Strip |
| R | Soft | ≤585 | ≤570 |
| 1/4I | 1/4 Hard | 585~725 | 520~630 |
| 1/2I | 1/2 Hard | 655~795 | 590~700 |
| 3/4I | 3/4 Hard | 725~860 | 600~770 |
| I | Hard | ≥850 | ≥700 |
Typical Physical properties
| Density (g/cm3) | 8.2 |
| Electrical resistivity at 20ºC(Om*mm2/m) | 0.48 |
| Temperature factor of resistivity(20ºC~100ºC)X10-5/ºC | 3.7~3.9 |
| Curie point Tc/ ºC | 430 |
| Elastic Modulus, E/ Gpa | 138 |
